What is Shutter Mechanism in Cameras?
Shutter technology in cameras is a fundamental component that controls how light interacts with the camera's sensor. At its core, the shutter acts as a gate, determining how long the camera’s sensor is exposed to light. When you press the shutter button, the shutter mechanism opens to allow light to pass through the lens and reach the sensor. The duration for which this shutter remains open is critical because it directly affects the exposure of the image.
Exposure refers to how much light hits the sensor, which in turn affects the brightness and detail in the final photograph. A longer exposure allows more light in, making the image brighter, while a shorter exposure limits the amount of light, producing a darker image.
The shutter also plays a key role in controlling image sharpness. If the shutter is open for too long, fast-moving subjects can appear blurry because they have moved while the sensor is capturing the image. This is where the concept of motion blur comes into play. A quicker shutter speed freezes fast-moving subjects, capturing them with sharp details. On the other hand, a slower shutter speed allows you to capture motion, such as flowing water or moving vehicles, giving a smooth, blurred effect that adds artistic flair.
Understanding how the shutter controls both the timing and the amount of light that reaches the sensor is crucial for capturing high-quality images with accurate exposure and sharpness. The type of shutter used, whether mechanical, electronic, or a combination of both, influences how these factors interact and impacts the overall performance of the camera.
Type of Shutters
Mechanical Shutter
Physical metal or fabric curtains open and close in front of the sensor. Two curtains move in a precisely timed sequence to control exposure.
Pros | Cons | Best used for |
|---|---|---|
- Classic shutter sound | - Can cause slight camera shake | - Everyday photography |
Electronic First Curtain Shutter (EFCS)
Photo by Camera Zone
Starts exposure electronically (no initial movement), then uses a mechanical second curtain to end the exposure.
Pros | Cons | Best used for |
|---|---|---|
- Less camera shake | - Max shutter speed | - Portraits |
Electronic Shutter
No mechanical shutter. The sensor reads light electronically line-by-line when you press the shutter button.
Pros | Cons | Best used for |
|---|---|---|
- 100% silent | - Can cause weird bending in fast-moving shots (rolling shutter) | - Silent events |
Rolling Shutter vs Global Shutter
Rolling shutter and global shutter refer to the ways electronic sensors capture and read image data, which has a direct impact on image quality, particularly when photographing fast-moving subjects.
A rolling shutter captures an image by reading the sensor line by line, from top to bottom. While this method works well for still scenes, it causes issues with fast-moving subjects or rapid camera motion, often resulting in the "Jello Effect," where fast-moving objects appear bent or distorted. Since each part of the image is recorded at slightly different times, this can lead to noticeable distortions, commonly referred to as the "rolling shutter effect”.
Rolling Shutter Advantages
Higher frame rates
High-resolution BSI sensors
Higher native sensitivity
Lower noise levels
Higher dynamic range
Rolling Shutter Disadvantages
Rolling shutter artifacts with fast-moving subjects
Limited flash sync speeds
Global shutters work by capturing the entire image at once, with every pixel exposed simultaneously. This eliminates the motion distortions that are often seen with rolling shutters, making global shutters ideal for fast-moving subjects. Since global shutter sensors typically have larger pixels, they are more sensitive to light and can deliver sharper, clearer images, especially in low-light or high-speed environments.
To summarize, rolling shutter cameras are a great choice for capturing static or slow-moving scenes. They often offer higher resolutions with smaller pixels at a lower cost, making them well-suited for tasks like inspecting circuit boards, scanning documents, or monitoring stationary objects in industrial automation.
In contrast, global shutter cameras are the go-to solution for high-speed motion capture or when geometric accuracy is critical, such as in drone imaging, robotic vision, or fast production lines.
Global Shutter Advantages
No distortion of straight lines with fast-moving subjects
No limit on flash sync speed
Global Shutter Disadvantages
Lower frame rate
Lower native sensitivity
More noise
Lower dynamic range
Costly to manufacture
Feature Comparison
Feature | Rolling Shutter | Global Shutter |
|---|---|---|
Motion Distortion (Skewing) | Yes — causes skewing, wobble, or "jello" effect in fast motion | No — captures fast motion without geometric distortion |
Warping & Wobbling | Prone to warping with vibrations or panning | Eliminated due to simultaneous exposure |
Banding (Under Pulsed Light) | Susceptible — horizontal banding under LED/strobe lighting | Resistant — uniform exposure across entire frame |
Flash Synchronization | Limited — can only sync flash with part of the frame | Full-frame sync — excellent for strobes and short-duration lighting |
Resolution Potential | Typically higher with smaller pixels | Often lower resolution for similar sensor size |
Image Quality (Static Scenes) | Excellent — high dynamic range and low noise in still environments | Slightly lower image quality in static scenes |
Sensor Size & Complexity | Smaller, simpler design | Larger and more complex circuitry |
Power Consumption | Lower — more efficient in embedded and mobile setups | Higher — consumes more power due to memory and logic circuitry |
Latency & Readout Speed | Slower full-frame readout (due to sequential exposure) | Faster — ideal for real-time processing |
Cost | More affordable | More expensive |
Applications of Global Shutter Cameras
Mobile Mapping in Smart Cities
The global shutter is being used to map smart cities in asset management, environmental monitoring, Traffic and Mobility Management, etc.
Asset Management
In smart cities, mobile mapping systems such as SS360 MMS, equipped with global shutter cameras, play a crucial role in accurate asset management. These cameras capture sharp, distortion-free images even when the mapping vehicle is in motion, ensuring reliable documentation of streetlights, signage, and other public assets. This level of precision is essential for creating digital twins, assessing asset conditions, and maintaining up-to-date inventories. By eliminating motion artifacts, global shutter technology improves the quality of data used for planning maintenance, tracking asset lifecycles, and making infrastructure decisions more efficiently.
Environmental Monitoring
These cameras capture clear, undistorted imagery during motion, enabling reliable tracking of factors like vegetation growth, waste accumulation, and environmental hazards. High-fidelity data supports applications such as air quality assessment and vegetation management, especially in dynamic or hard-to-reach areas. By providing sharp visual input, global shutter technology strengthens decision-making processes and helps automate monitoring tasks that traditionally rely on manual inspection. One example of this technology in action can be seen in how Kodifly integrates global shutter cameras into its hardware to support advanced environmental monitoring applications.
Traffic and Mobility Management
These cameras capture high-quality, blur-free images even in fast-moving urban environments, allowing for precise detection of traffic signs, road markings, and vehicle movements. Multi-lens setups in these systems provide both a broad overview of the traffic scene and high-resolution images for automatic number plate recognition (ANPR). When combined with Frame Parity Flashing, this configuration ensures crystal-clear captures of both reflective and non-reflective license plates, which is crucial for enforcement, tolling, and vehicle tracking. By delivering distortion-free and highly detailed imagery, global shutter technology improves the reliability of real-time traffic monitoring and supports safer, more efficient transportation networks.
Cinematography and Sports Analysis
High-End Cinema Cameras
Global shutter cameras are becoming a staple in high-end cinema productions, not only for eliminating distortion but also for providing filmmakers with greater freedom in their shooting techniques. Without the need to compensate for motion artifacts, directors can confidently choreograph fast dolly shots, whip pans, or handheld sequences without compromising image quality. This allows for more creative flexibility on set and reduces the need for reshoots or visual cleanups in post-production, helping to keep both time and budget on track.
Sports Analysis
In professional sports, milliseconds and millimeters make all the difference. Global shutter cameras provide analysts with reliable frame-by-frame footage that captures every detail of the game, from the exact foot placement in a sprint to the spin of a tennis ball mid-serve. These systems also enable multi-angle playback and AI-based motion tracking, making them essential for both real-time decisions and post-match evaluations.
Action Cinematography
When filming extreme action, whether mounted on a chase car, a drone flying through obstacles, or a helmet cam speeding down a mountain, the equipment needs to be both tough and accurate. Global shutter cameras perform well under intense motion and harsh environments, delivering clean footage that remains intact when slowed down or stabilized. For content creators and stunt teams alike, this reliability makes them the camera of choice for capturing adrenaline-fueled moments without compromise.
